Photo-electric timer AHC15T

Rating:

The AHC15T is a precision, digital, programmable time controller that also has an intelligent auto-correction feature for the set times in relation to the latitude where it is installed. So you're sure that controlled lighting will always turn on after sunset and turn off at sunrise!

Rate this product Add to wishlist

Manufacturer: ALION

Price: 29.90лв. VAT Incl.

Quantity	1+	3+	5+
List Price	29.90лв. VAT Incl.	28.40лв. VAT Incl.	26.91лв. VAT Incl.

SKU: 50349

Weight: 0.250 Kgs

Quantity: 0

Notify me when the product is available

Application

It is used in the automatic control of street, park and garden lighting, as well as in management of light commercials, showcases, signs, signs, panels etc. A key feature of the device is the built-in auto-correction feature for set-on and off times, in terms of latitude and longitude, with the use of which saves significant electricity costs.

Astronomical, programmable time relay

model - AHC15T;
installation - eurohard (35 mm DIN IEC standard);
accuracy - 2 sec. per day;
supply voltage - 180 VAC-250 VAC / 50 Hz;
contacts - NO + NC;
load capacity of the contacts - 250 VAC / 16 A active load;
electrical / mechanical contact durability - 1,000,000 times;
setup mode - programs with 8 turns + 8 shutdowns, minimum interval of 1 minute;
built-in battery capacity - 2 years;
indication - LCD display;
operating temperature - from -10 ° C to + 40 ° C;
power consumption - 4 VA;
dimensions - 83x36x66 mm.

Additional information

When starting up, plug the timer into the power supply and leave it on for 12 hours to charge the battery, then press the R (reset) button with a sharp object to reset the data.

Operating Instructions for Timer AHC15T (BG) [PDF, 316.11 KB]
