Name: Programmable Weekly Timer ATHC20A, 230VAC, NO+NC, 20A/250VAC
Brand: VEMARK
SKU: 102950
Price: 16.34 EUR
Availability: InStock

Programmable Weekly Timer ATHC20A, 230VAC, NO+NC, 20A/250VAC - 1

ATHC20A timer for programming ON / OFF of consumables in the preparation of a weekly schedule. For DIN rail mounting. It is important to consider the load carrying capacity of the contacts when connecting different types of loads.

Manufacturer:

VEMARK

Model:

ATHC20A

Individual Warranty:

24 months

Company Waranty:

12 months

Weight:

0.100 Kgs

Buy on installment with tbi bank

for a total cart value over € 50

Availability

Available online

200 pcs.

On site in Vikiwat shop

the price on site may be different

out of stock

See quantities

-14%

online

€ 16.34 / 31.96 лв

~~€ 19.00~~

The offer is valid from 04.08.2026 to 04.08.2026

Buy on installment with tbi bank

for a total cart value over € 50

SKU: 102950

Operating functions

ON/OFF mode - the timer can be programmed to turn on/off 18 times per day. The 24-hour program can be run for one day, every day, selectable groups of days (e.g. Monday-Friday, Saturday and Sunday, Tuesday Thursday and Saturday, etc.). The minimum interval is 1 min.;

"impulse" mode - the timer can be set to turn on a consumer for a certain time (up to 1 hour) 18 times a day and to be executed one day, every day, selectable groups of days (e.g. Monday-Friday, Saturday and Sunday, Tuesday Thursday and Saturday, etc.). The minimum interval is 1 sec.;

"countdown" mode - the timer can be used to turn off a consumer after a certain time (from 1 sec. to 99 min. and 59 sec.);

"pause" mode (AUTO OFF) - in this mode the timer temporarily stops working, and the set programs do not need to be deleted.

"forced ON/OFF" mode - using the MANUAL button, the relay (output) can be forcibly turned on/off, except when the timer is in "countdown" mode;

Additional information

For safe use, it is mandatory to follow the product's instructions for the maximum permissible power of the devices connected to it.

When initially operating, connect the timer to the power supply and leave it on for 12 hours to charge the battery, then press the R (reset) button with a sharp object to reset the information.

Timer ATHC20A programmable weekly 230VAC NO+NC 20A/250VAC

Programmable Weekly Timer ATHC20A, 230VAC, NO+NC, 20A/250VAC

Application

Operating functions

Additional information

Technical parameters of Programmable Weekly Timer ATHC20A, 230VAC, NO+NC, 20A/250VAC

Technical documentation of Programmable Weekly Timer ATHC20A, 230VAC, NO+NC, 20A/250VAC
