Power Adapter, 24VDC, 3A, 72W, 100-240VAC, 5.5x2.5mm, stabilized, impulse, UP072S

Power Adapter, 24VDC, 3A, 72W, 100-240VAC, 5.5x2.5mm, stabilized, impulse, UP072S
- 1

POWER ADAPTER 100-240VAC, 24VDC, 3A - 2

POWER ADAPTER, UP072S, 100-240VAC - 3

POWER ADAPTER, UP072S, 100-240VAC - 4

Power Adapter, 24VDC, 3A, 72W, 100-240VAC, 5.5x2.5mm, stabilized, impulse, UP072S
- 1

POWER ADAPTER, UP072S, 100-240VAC - 3

POWER ADAPTER, UP072S, 100-240VAC - 4

Power supply adapter, UP072S, input voltage 100 - 240 VAC, output voltage 24 VDC, output current 3 A.

Manufacturer:

DeTech

Model:

UP072S

Individual Warranty:

24 months

Company Waranty:

12 months

Weight:

0.385 Kgs

Availability

Out of stock online

On site in Vikiwat shop

the price on site may be different

out of stock

BGN 32.90 VAT Incl.

Notify me when available Close

Notify me when the product is available

Prices for quantities (VAT Incl.)

1+

BGN 32.90

3+

BGN 31.26

5+

BGN 29.61

10+

BGN 27.97

20+

BGN 26.32

SKU: 32185

Description Specifications Reviews

Description

Power adapter

To properly select the power of the device, it is advisable to consult a specialist. The power must be based on the power of the consumers and the type of load:

The nominal power of the device must be 20-30% higher than the load capacity of the consumer at an active load (heaters, electric ovens, furnaces, stoves, incandescent lamps, etc.). This is due to the high starting current of the loads. When the load is switched on and during repeated short-time modes, the load over a short period significantly exceeds the nominal parameters specified in the load characteristics.

When the device is used in conjunction with inductive load consumers, the power must be 3 to 5 times the power consumption of the load! (fluorescent lighting, electric motors, pumps, air conditioners, refrigerators and freezers, etc.).

When the device is used for consumers with a capacitive load, the selected power must be 5 to 10 times greater than the power consumption of the load! (pulse chargers, LED drivers, pulse power supplies, etc.).

If these instructions are not complied with, it is possible for the device to be overloaded and stop functioning, and the warranty will not cover the damage.

Specifications

Technical parameters of Power Adapter, 24VDC, 3A, 72W, 100-240VAC, 5.5x2.5mm, stabilized, impulse, UP072S

Brand:

DeTech

Output voltage:

24 [VDC]

Output current:

3 [A]

Output power:

72 [W]

Input voltage:

100~240 [VAC]

Adapters and chargers kind:

stabilized

Tips:

5.5x2.5mm (Universal)

Cable length:

1.35 [m]

Dimensions:

170x46x30 [mm]

Model:

UP072S

Adapters and chargers type:

AC-DC
